International Newsletter vol.46 2011/6
6.20.2011 FORUM8 http://www.forum8.com/
UC-win/Road Ver.5.02.00 has been released*Free upgrade for Users of UC-win/Road Ver5.00.00.
FORUM8 has released UC-win/Road Ver.5.02.00 which has the variety of new functions on June 9, 2011.
Users of UC-win/Road Ver5.00.00 can upgrade to a new version without charge.
The following features were added to Ver5.00.00 in this upgrade.
Increased realism in the movement of overall vehicle movement, engine, and each transmission from engine to wheel.
 |
 |
 Setting of specification |
|
 |
|
| Image of stopping distance and road surface |
Explanation of understeer |
Improvement of collision effect such as suspension effec at the time of shoulder collision.
The model of vehicles or a pedestrian is recorded, and a replay function is also supported.<br>
Driving by manual drive or scenario function is supported as well.
| Behaviors to be replayed | |
| Vehicle | Coordinate, roll, pitch, yaw, turn signal, brake lamp |
| Pedestrians | Coordinate, behavior, roll, pitch, yaw |
| Traffic signal | Lighting status |
| Context | Context while performing scenarios |
 |
 |
| The accident while driving simulation can be checked
from outside of vehicle |
|
With placement of audio source and audience on 3D VR space, the acousticextent is simulated.
The Noise simulation analysis will be supported by supercomputer cloud system. It is expected that the speed and quality of analysis will be improved.
*An acoustic pressure level at each sound receiving point on sound receiving surface is analyzed in consideration of influence of ground surface, structures, buildings, etc.
*It's composed of the functions- preprocessor (input unit), main processor (analyzer) and postprocessor (result)
*The display in sound pressure level is available by contour figure, contour line, a grid and spherical shape.
 |
 |
| Images of noise analysis |
|
The function to create road alignment (plane, longitudinal, crossing) from point cloud information is added.<br>
Revised function of sequence of points and user interface have been improved.
 |
 |
| Effect by point line revision function |
Editing the column of the center position |
The color and strength of lighting in tunnel space can be set by each tunnel. This affects are applied for the traffic entering to the tunnel and the roadside objects.
 |
 |
| Image of tunnel entrance and exit |
Realistic representation of vehicle's cockpit while driving in the tunnel |
*Operation display of steering handle of cockpit
*Setting of angles from each mirror inside of cockpit and angle of view are supported.
*It supports the setting of an additional mirror in addition to a right-and-left mirror and a room mirror.
 |
  |
Setting of the friction coefficient curve is supported.
 |
 |
| Difference of friction factor on road surface |
Setting the click of 3D model as an event is supported.
 |
 |
*Speed control while walking has been improved.
*Display of walker avatar (MD3) by walking simulation.
*The operation method of walking by using only mouse is added.
*It supports game controller operation in walking simulation.
 |
 |
| Walking simulation, display of avatar |
|
The control from outside of the active steering handle is supported.
It's available for the research of automated vehicle operation and the review of interaction of the vehicle and driver.
Wiper expression on windscreen at the time of raining or snowing is supported.
The settings such as wiper's size, condition of flow of raining and texture of snowing are available.
The latest version of InRoads is supported.
 |
| Data linkage of InRoads and UC-win/Road |
We are pleased to inform you that we received "the Special award of the 8th CSAJ Alliance Award"for the in-house developed software, SaaS type of 3D real-time simulation software "UC-win/Road for SaaS (Current name is VR-Cloud(TM)" and SaaS type of civil design software "UC-1 for SaaS" from Computer Software Association of Japan (CSAJ)(Chairman: Shigefumi Wada) on June 8, 2011.
*Name of award: The 8th CSAJ Alliance Award-Special Award
*Applying name: FORUM8 Co., Ltd
*Awarded products:
1.SaaS type of 3D real-time simulation software "UC-win/Road for SaaS(Current name:VR-Cloud(TM))"
2.SaaS type of civil design software "UC-1 for SaaS"
 President Yuji Ito receiving the award |
Award certificate and plaque |
||
|
 |
| Screen of UC-win/Road for SaaS(Current name :VR-Cloud(TM)) |
Screen of UC-1 for SaaS |
||
|
 |
<Overview of the award>
The CSAJ Alliance Award is for the company who made a presentation for a year in the alliance business network event organized by CSAJ alliance business committee. The judgement is performed based on the actual achievement and potential of affiliation, the number of business, future possibilities, marketability, and technology.
In this 8th award, the encouraging award and the special award are selected for each.
We received this award for two products. "UC-win/Road for SaaS (Current name: VR-Cloud(TM)"is the system which allows the use of existing package software via Internet. It is expected that viewing VR data in such an environment with PC and Smartphone will improve the market more and more in future. "UC-1 for SaaS"is the SaaS type of "UC-1 series". A few thousand of licenses have been sold as the package product. It is expected that this will encourage market development and include customers who have not be able to adopt this product due to the cost issue.
[Associated URL]
UC-win/Road for SaaS
(Current name:VR-Cloud(TM): http://www.forum8.co.jp/english/uc-win/RoadforSaaS-e.htm
Supercomputer cloud service: http://www.forum8.co.jp/topic/up91-p37-e.htm
The CSAJ Alliance Award is for the company who made a presentation for a year in the alliance business network event organized by CSAJ alliance business committee. The judgement is performed based on the actual achievement and potential of affiliation, the number of business, future possibilities, marketability, and technology.
In this 8th award, the encouraging award and the special award are selected for each.
We received this award for two products. "UC-win/Road for SaaS (Current name: VR-Cloud(TM)"is the system which allows the use of existing package software via Internet. It is expected that viewing VR data in such an environment with PC and Smartphone will improve the market more and more in future. "UC-1 for SaaS"is the SaaS type of "UC-1 series". A few thousand of licenses have been sold as the package product. It is expected that this will encourage market development and include customers who have not be able to adopt this product due to the cost issue.
[Associated URL]
UC-win/Road for SaaS
(Current name:VR-Cloud(TM): http://www.forum8.co.jp/english/uc-win/RoadforSaaS-e.htm
Supercomputer cloud service: http://www.forum8.co.jp/topic/up91-p37-e.htm
